Structure

• Frame Size (L - W -H): 590x980x160mm

• Working Size ( X - Y): 460 x 810mm, area extended design

• Dot Pitch: 0.075mm

• Pixel：6133 x 10800 px

• Frame Material: All-aluminum alloy and PC material hybrid frame

• Structure Technology: Y-axis fit adjustable design, X-axis stress fit assembly

• Structure Feature: Fit, High precision, stablize, smooth, no oil, easy maintenance, long life

• Vertical Carving: Yes

• Motor Size: 42 x 42 x 40mm

• Motor Drive Current: 0.9A

• Module Height Adjuster： Yes

• Limit Switch: Yes

• Home: Rear Left

• Origin: Front Left

• Max Move Speed:X:1000mm/s,Y:750mm/s(with A40640 module 204g)

Control System

• MCU: 32-bit MCU

• BLE: Yes

• MEMS: Yes

• Input: 12V 5A

• Compatible Modules: All NEJE 12V 4pin Laser Moudle

• ON/OFF Switch：Yes

Software Service

• OTA Upgrade:Update NEJE firmware, GRBL firmware, update latest software via NEJE Win software.

• LaserGRBL: Yes, Added low light function, added M8, M7, emergency stop extended automatic control, optimized GRBL interaction.

• Lightburn: Yes, Added low-light display and can be adjusted, added M8, M7, Door function automatic adaptation.

• NEJE Win Software: Yes, It is recommended to open the NEJE software to update to the latest firmware for the first time use.

• Off-Line Working: Yes, In NEJE Win software and NEJE APP mode, when the image is transferred to the device, it can work independently from the computer or mobile phone.

• Repeat Engraving:Yes, After the engraving or cutting is completed, the device will not lose the location information, if you are not satisfied with the work, you can continue to work.

• NEJE Android APP: Yes

• NEJE iphone/iPad APP: Currently not supported, under development

• NEJE Cloud Gallery Service:Yes

• Software Download:Https://neje.wiki

E40 SPECIFICATION

Module: NEJE E40

Focus: 0.06x0.06mm

Focus method: fixed ( 3mm from the radiator  )

Optical power: Pulse 11W+, CW 10W+

Wavelength: 450nm

Weight: 280g

Module Size: 40x48x130 mm

Input: DC 12V 4A

Interface: 4pin PH2.0 + ( 2pin DC12v extra power )

Compatible with: NEJE 3 Max, NEJE 3 Pro, NEJE 2s Max, NEJE 2s Plus, etc...

Power Control: PWM Power Modulation

Fan: Double Ball High Life Fan

Drive: NEJE Smart Quiet Drive, Built-in static elimination technology.

Surge Protection: Yes

Smart Feedback: Yes

Temperature Feedback: Yes

Temperature control: 45℃

air pump: 0.5-1.5mpa clean air

Air interface: 4mm pvc trachea

Protective window lens: Yes ( withstand 1000℃ )

Original registered brand: Yes

Warranty: 2 years

NEJE A40640 Laser Module

• Radiator Size: 40 x 50 x 60 mm

• Weight: 204g

• Speed of the Fan: 10600RPM(Double ball bearing)

• Interface: PH2.0 4Pin

• Drive Design: Built-in

• Input: 12V 4A +

• Optical Power: 10W +

• Wavelength: 450nm

• Laser Class: Class 4

• Number of Diodes: 2

• Light Source: 2 X LD + FAC Tech + C-Lens

• Focus Spot： o.13x0.13mm - 0.18xo.18mm,

• focus on 33mm: 0.13 x 0.13 mm,

• focus on 55mm: 0.18 x 0.18mm

• PWM Input: VPP(3.3-12V), Recomend 1KHz,

• Quiet Design: Drive the built-in control ic, judge the working state and adjust the fan work.

• Max Cutting & Carving Depth: 18mm (The data is tested by NEJE users, and it needs to be done under more accurate focusing and adding correct and certain strength of air assist.)

• Brushed Stainless Steel: Yes

• Mirror Stainless Steel: Yes
