1.5KW/2.2KW Water Cooled Spindle + 110V/220V Inverter + 65/80mm Clamp + Water Pump/5m Pipe + 13pcs ER20/ER11 for CNC Wood Router

Packages include:

2.2kw set:

1.5kw set:

Feature:

1. CNC Spindle Motor

Size:65mm(1.5kw) / 80mm (2.2kw)

Power:1.5KW / 2.2KW

Voltage:110V / 220V (Automatically match different countries）

Frequency:0-400Hz

Speed:0-24000rpm

Water Cooling：ER11 /ER20 collet

Runout off: less than 0.1mm

Grease Lubrication

Bearing:4pcs Bearing C7005X2  C7002X2

2.Inverter (Automatically match)

Type: 1.5KW-220V / 2.2KW-220V / 1.5KW-110V / 2.2KW-220V

Input: 110V/220V, AC 50Hz

Output: 0-220V / 0-110V, AC 3-phase

Frequency: 0-400Hz

the parameter of the inverter is :

Note:If there is no problem, please do not change the parameters of the inverter.

Variable Frequency Drive VFD Inverter  110V/220VAC

1)PID control; advanced calculus PID closed-loop arithmetic, quick responding speed and high suitability;

2)Easy PLC function can realize 16 legs of speed and inverter control function;

3)RS485 communication port, adopting standard international MODBUS main circuit control;

4)With extremely strong anti-jamming capability

5)Low output ratting torque0.5HZ-150%, low speed running ability;

6)Carrier adjustable by 16KHZ, completely soundless working environment;

7)Broad voltage working area, normal running in 304V-456V;

8)Auto voltage regulation (AVR) technique, for ensuring the inverter load capability;

9)Various control technique by both synchronization and non-synchronization, dynamically realize fast starting without changing brakes;

10)With perfect error protection and short circuit starting protection capability;

3.water pump

AC Voltage: 220v-240v/50hz

Flow: 3500L / h

Power: 80w

Qmax:3500L/H

Structure:single-stage pump

Pressure :high pressure

Don't operata without water.

Caution:read the instrution carefully before using !

4.ER20 Collet 1 Set:

Gripping Range: 1MM to 13MM(1,2,3.175,4,5,6,7,8,9,10,11,12.7,13mm)

5.5M Water Pipes:

Size:5M 6mm (ID)*8mm (OD)

6.Spindle Motor Clamp :

Diameter: 80mm

Material: Aluminum,Surface sandblasted

Application: Wood working industry rourter, such as wood door milling engraving and cutting, furniture producing

Reminder

A new electric spindle is received to start from low speed 6000. It will increase by 3000 after every ten minutes, and it will be used normally after 24,000 revolutions. The bearing inside the new spindle needs to be preheated and run-in, remember! In order to extend the service life of the spindle, it is best to start the test run for 10-15 minutes when the spindle is used normally.

Take the 24000 rpm spindle as an example, the other speed spindles are the same.
