You May Be Wondering
1. How is the quality?
100% satisfied, click for more customer reviews onFoxAlien 4040-XE.
2. Is there a warranty?
All FoxAlien CNC machines are protected by official 1-year warranty since the date of delivery.
Tips: There are 6800+ FoxAlien cnc router owners and fanciers in our Facebook group. Click to Join FoxAlien CNC Router User Facebook Group. All your questions will be answered in there.
3. Do I have to pay for tax?
We have warehouses in the US and Europe, so if you choose to ship from Europe and the US, you won't have to pay customs duties. This shipping always takes about 3-7 days.
Please Note ! ! ! ! ! If you do not choose overseas warehouse delivery. Please make sure your address is correct and complete before payment! We usually ship your order within 48 hours using AliExpress Standard Shipping, it usually takes around 15-30 days to ship, duties may apply. Please understand that customs duties are not under our control, if you are in doubt about this, please consult your local customs.
4. Can a laser be installed for etching?
Yes, it supports laser etching. Compatible with all FoxAlien laser modules, FoxAlien's 20W laser and 40W laser. For laser engraving, it also fits R57 rotary rollers.
TIP: Click to see adding the laser to FoxAlien CNC machine 404-XE from Youtube.
5. Can this CNC machine cut/engrave metals like Zinc Brass Aluminum?
Yes it can. You can use it to machine 7075-T6 or 6061 aluminum.
TIP: Click to see FoxAlien CNC machine 404-XE cutting 5mm aluminum from Youtube.
6. Can this CNC machine cut/engrave all kinds of material such as wood, leather, MDF, acrylic, foam, resin, nylon, carbon fiber, PCB ?
Yes it can. TIP: Click to see FoxAlien CNC machine 404-XE engraving and cutting acrylic from Youtube.
7. What software does this work with? and include the software?
This CNC machine is based on GRBL and is compatible with GRBL control software. We provide free open source software - Candle, which can also be downloaded online / if you need other software, you may need to buy it yourself.
8. Can I run this directly connected to my PC?
Yes, this CNC machine can be connected to PC through USB cable.
9. Do I have to load cad software to do 3D engraving?
This machine moves on all 3 axes (x, y, and z) simultaneously, what we call true 3-axis CNC in the industry. It cannot 3D sculpt and is not compatible with Mach3 software. But it can do relief.
10. Can the 4040-XE power supply and frame handle a spindle over 300w? Maybe like a 500w or 600w spindle?
It comes with a 300W spindle. It is the largest spindle the machine can support. But this machine can also fit a DWP611 router with a 69mm diameter z-clamp.
Specifications:
Model: 4040-XE
Active Working Area: 15.75 x 15.75 x 2.17 inch (400*400*55mm)
Spindle Power: 300W
Stepper Motor: NEMA 23
Accuracy: 0.1mm
Maximum Moving Speed: 2000mm/min
Input Voltage: 110V/220V
Input Current: 110V/10A; 220V/5A
Control Method: Computer & Controller
Support Software: Compatible with Grbl-control software
Support OS: Windows XP/7/8/10, Linux, Mac OS
Machine Weight: 57.6 pounds (26.5kg)
Machine Size: 29.92 x 24.4 x 14.17 inch (760*620*360mm)
Package List:
1x 4040-XE CNC Router (main parts pre-assembled)
1x Controller
1x 300W Spindle
1x MDF working table
10x Engraving Bits
10x Nano Blue Coating End Mills (0.8mm-3.175mm, 1/8” shank)
4x Hold-down Clamps
1x Power Supply
1x USB Card Reader
1x Memory Card
1x Z Probe
1x User Manual
Packs of screws and tools
Specifications:
Main Features:
● 4040-XE CNC Router uses 300W spindle and NEMA23 stepper motors, which are more powerful and efficient. Max moving speed is 2000mm/min and spindle speed range is 0~10000.
● Control board, power supply, emergency stop, and wires are integrated into a newly design box, which is simple for operation, easy to clean and safe. The controller has a 3.5” touchscreen LCD which also functions as an offline controller.
● It’s capable to engrave, cut and drill many different kinds of material such as wood, metal, MDF, acrylic, foam, resin, nylon, fiber carbon, PCB and etc. It’s great for home use and business.
● Large engravable area of 15.75”x15.75”x2.56” (400x400x65mm). It’s capable to handle both small and large material. The CNC machine is based on GRBL, it is compatible with GRBL-control software.
● Easy assembly. Main parts are pre-assembled, it only takes 15-30mins to fully assembly. Wires are labeled clearly for fast connection and bundled into drag chain for easy management.
