DIY LY drawbot pen drawing robot machine lettering corexy A2 A3 A4 engraving area frame plotter robot kit for drawing writing support laser
(RE:All kits are disassembled,when got parcel,could follow manual to install.)
Difference with guide rail version: Guide rail version add more 3 guide rails,more precise & more accurate.
L10087 Normal Version A2(Support Laser)
Parameter description:
Equipment Size: 650MM * 450MM * 120MM (L * W * H)
Engraving area: 600MM*400MM(A2)
Power supply: 12V, 2A
Operation system: Win XP/Win7/Win10
Software: Inkscape
1, 1*special controller （support laser engraving）If need laser head can contact with sales.
2, 2* stepper motor
3, 1*9g Servo
4, 1*12V adapter
5, 1 set*2020 aluminum
6, 1 set screw and nut
7, 1 set bearing
8, printed parts
9, other parts
L10088 Guide Rail Version A2(Support Laser)
Parameter description:
Equipment Size: 650MM * 450MM * 120MM (L * W * H)
Engraving area: 600MM*400MM(A2)
Power supply: 12V, 2A
Operation system: Win XP/Win7/Win10
Software: Inkscape, UGS
1, 1*special controller （support laser engraving）If need laser head can contact with sales.
2, 2* stepper motor
3, 1*9g Servo
4, 1*12V adapter
5, 1 set*2020 aluminum
6, 1 set screw and nut
7, 1 set bearing
8, printed parts
9, other parts
L10068 Guide Rail version A3L
Parameter description:
Equipment Size: 630MM * 510MM *120MM (L * W * H)
Engraving area: 420MM*297MM(A3)
Power supply: 12V, 2A
Operation system: Win XP/Win7/Win10
Software: Inkscape
1, 1*special controller （support laser engraving）If need laser head can contact with sales.
2, 2* stepper motor
3, 1*9g Servo
4, 1*12V adapter
5, 1 set*2020 aluminum
6, 1 set screw and nut
7, 1 set bearing
8, printed parts
9, other parts
L10065 Normal Version A3L
Parameter description:
Equipment Size: 630MM * 510MM *120MM (L * W * H)
Engraving area: 420MM*297MM(A3)
Power supply: 12V, 2A
Operation system: Win XP/Win7/Win10
Software: Inkscape,UGS
1, 1*special controller （support laser engraving）If need laser head can contact with sales.
2, 2* stepper motor
3, 1*9g Servo
4, 1*12V adapter
5, 1 set*2020 aluminum
6, 1 set screw and nut
7, 1 set bearing
8, printed parts
9, other parts
L10066 Guide Rail version A4
Parameter description:
Equipment Size: 560MM * 410MM * 120MM (L * W * H)
Engraving area: 297MM*210MM(A4)
Power supply: 12V, 2A
Operation system: Win XP/Win7/Win10
Software: Inkscape, UGS
1, 1*uno controller
2, 1*CNC V3 shield
3, 2*A4988 stepper drive chip
4, 2* stepper motor
5, 1*9g Servo
6, 1*12V adapter
7, 1 set*2020 aluminum
8, 1 set screw and nut
9, 1 set bearing
10, printed parts
11, other parts
L10064 Normal Version A4L
Parameter description:
Equipment Size: 510MM * 410MM * 120MM (L * W * H)
Engraving area: 297MM*210MM(A4)
Power supply: 12V, 2A
Operation system: Win XP/Win7/Win10
Software: Inkscape
1, 1*special controller （support laser engraving）If need laser head can contact with sales.
2, 2* stepper motor
3, 1*9g Servo
4, 1*12V adapter
5, 1 set*2020 aluminum
6, 1 set screw and nut
7, 1 set bearing
8, printed parts
9, other parts
