4 axis CNC controller USB Stick G code Spindle Control Panel MPG Stand Alone lathe milling machine controller
1. Product Introduction
TC5540H is an upgrading version of TC55. It can control 4 feeding axis, 1 analog spindle. It is equipped with 16
input port and 8 output port, supporting importing G code files from USB stick and boot picture. Support saving the current coordinates after power off.
2. Technical Specifications
Minimum data unit 0.001 mm
Maximum data size ± 99999.999mm
Maximum Speed: 24m/min (pulse is 0.001mm)
Maximum pulse output frequency 400KHz
Axis 1-4 (X,Y, Z, C)
X,Y,Z axis can conduct linear interpolation, X,Y can do circular interpolation.
Electric Gear: numerator :1-99999 denominator: 1-99999
USB: Importing program and boot picture
Isolated I/O port
Maximum Program Line: 1000
Maximum Program: 99
RAM: 128M
External Manual Operation: motor clockwise and counter clockwise spinning, start, pause, alert and stop
G code and M code
One panel MPG
3.5 inch color LCD, pixel 320*240
Analog Spindle Output: one 0-10v analog spindle
Support both servo and stepper motor
Support metric system, round, division, degree, inch etc.
Support USB connecting computer as power supply.
3. Pacakge includes
One controller
One USB cable which you connect between computer and controller as power supply.
One pack of Screws and Nuts
We provide free 24V 1A power supply as gift. Quantity is limited, please order soon.
After you make the order, please leave us your email address, we will send you the detailed manual as well as the Q and A document. Q and A document will be updated with time.
We are the only licensed seller on aliexpress for selling TOPCNC TC55H, your right will be fully protected and full round technical support will be provided. If you have special requirements for controller, you can talk with us, we also provide customerized designing service.
We can produce and design CNC Controller cabinet. You can send us your requirements for projects.
