Electric Router
Door lock installation, quick trimming
Engraving and routing, slotting and opening
Full copper motor
Low resistance bearings
Ergonomically designed body
Increase comfort and control
2 different collet nuts : 6.35mm / 8mm
According to different types of work, milling cutters with different sizes of shanks can be installed
Self-locking wrench
Control the base lift.Work more accurate.
Control knob positioning slot depth
When the machine is working down, it touches the adjusted position and stabilizes to the depth.
Clear and accurate scale
Easier work, less mistakes
Products Detail
1.Scale adjustment knob | 2.Scale | 3.6-speed speed control button |
4.Scale fixing knob | 5.Collet nut | 6.Fine depth adjustment knob |
7.External carbon brush | 8.Start switch | 9.Self-locking wrench |
|
|
|
template | spanner | carbon brush |
|
|
|
straight guide | collet nut | dust tube |
Product name: | Electric Router |
|
Rated Voltage/Frequency: | 220V-240V～50Hz | |
Rated power input: | 1500W | |
Chuck diameter: | 6.35mm/8mm | |
No load speed: | 9000-30000r/min | |
Weight: | 4.6kg | |
Cutting capacity: | 50mm |
Product name: | Electric Router |
|
Rated Voltage/Frequency: | 220V-240V～50Hz | |
Rated power input: | 1050W | |
Chuck diameter: | 6.35mm/8mm | |
No load speed: | 11500-32000r/min | |
Weight: | 3.8kg | |
Cutting capacity: | 50mm |
Product name: | Electric Router |
|
Rated Voltage/Frequency: | 220V-240v~50Hz/60Hz | |
Rated power input: | 2100W | |
Chuck diameter: | 1/4in，3/8in，1/2in | |
No load speed: | 8000-23000r/min | |
Weight: | 6.3kg |
15PCS ROUTE BIT SET | |||||
Chamfer Bit | |||||
Trimming function | |||||
|
|
|
|
| |
Round Over Bit | Chamfer Bit | Cove Bit | Roman Ogee Bit | Flush Trim Bit | |
Slotted openning/engraving function | |||||
|
|
|
|
|
|
Double edged straight knife | Single blade straight knife | Dovetail Bit | Panel Pilot Bit | Core Box Bit | 'V'Grooving Bit |
Milling cutter installation
Step 1: Hold down the spindle lock and use a wrench to loosen the nut counterclockwise
Step 2: Insert the milling cutter from the nut
Step 3: Hold down the spindle lock and tighten the nut clockwise with a wrench
Note: The nut and the large chuck are factory-made in the machine, and the small collet is attached as an accessory with a hex wrench in the bag.
