Power Supply Tool Parts 60V/30A KPS6030D High Precision Adjustable LED Dual Display Switching DC
AC input: AC 220V ± 10% 50Hz
Can be customized: 110V ± 10% 60Hz
Output voltage: 0-60V
Output current: 0-30A
Output power: 1800W
Power supply stability rate: ≦ 0.3% + 10mV
Load stability rate: ≦ 0.5% + 30mV
Ripple noise: ≤0.5% + 10mV (rms)
Voltage value display Three-digit LED digital tube Accuracy: ± 1% +1 word
Display resolution: 0.1V
Current value display Three-digit LED digital tube Accuracy: ± 1% +1 word
Display resolution: 0.1A
Output overvoltage protection Built-in O.V.P protection, some models can be set externally
Output overcurrent protection Current limit, overload, short circuit constant current output
Over temperature protection Built-in O.T.P protection, the protection value is 85 ℃ ± 5%, the output will be closed after protection
Voltage setting Coarse and fine adjustment
Current setting Coarse and fine adjustment
Output polarity Output positive (+), negative (-) can be arbitrarily grounded
Cooling method Forced air cooling by temperature control circuit
Operating environment Temperature: 0 ℃ ~ 40 ℃; Humidity: 10% ~ 85% RH
Storage environment Temperature: -20 ℃ ~ 70 ℃; Humidity: 10% ~ 90% RH
Note: All values are typical values, so this value will be exceeded under different loads or under other conditions. Accuracy is measured in the voltage detection state of the load. Under the condition of temperature error and component aging, there may be deviation between the actual value and the rated value.
