Economic Upgraded IR BGA Model LY M770 BGA Rework station 220V 2 zones manual operation 1900W

Feature

This model maybe the cheapest 2 zones infrared bga rework station,if you are new bie,or have limited budget,you can consider of this model.

Specs


Zones

2 zones

Top Size

60*60mm

Top Power

300W

Bottom size

240*80mm*2 pcs

Bottom Power

1600W

Machine size

450*450*460mm

Power

220V,50/60HZ

Gross weight

20KG

Operation

Manual

Software

Not support

The parameters and performance indicators:

1. The rework station suitable for notebook computer motherboard, desktop computer motherboards, computer and server motherboard, motherboard, motherboard, large game machines, communications equipment, motherboards, LCD TV motherboard, motherboard, print circuit board repair.

2. The BGA chips rework station can be very effective in replacing the stack memory, the replacement of the BGA chip, memory below will not take slurry.

3. The rework station can be very successful in solving BGA chip heated foaming problem. (constant temperature 100 degrees available preheating.

4. Preheat to repair the motherboard 1-2 minutes. Then heating.

5. The rework station can replace CPU notebook memory slot to facilitate the.

6. BGA chip to be an easy job to replace glue sealing, sealing glue chip to the rubber (hot-air or in addition to adhesive glue).

7. The replacement of the BGA chip, the circuit board can not turn yellow.

8. The rework station using infrared preheating and infrared heating, lower preheating station, PCB board for preheating, ensure that the PCB plate can not be deformed, preheating station area of 245*180. Can fully meet the desktop and notebook computer repair.

9. Rational design of support structure, the replacement of the BGA chip is not deformation, very convenient and practical.

10. The rework station can do circuit board drying and circuit board shaping.

The rework station welding success rate is almost 99%, if can't achieve this goal, probably because of the new machine, please try it a few times.

Specifications

01. Applicable to laptop motherboard, desktop motherboard, XBOX-360, server motherboard, digital products etc..

02. Two heating zones, independant heating, upper heating 300W, bottom preheating 1600W

03. Maximum heating temperature : 500 degree

04. Used high accurate Intelligent temperature controller, make more accurate temperature controlling

05. Movable heater, easy and convinient to use

06. Infrared heating panel, independant controlling heating

07. Brilliant-designed Universal circuit board structural support, weld zone part non-support, none sink

08. Bottom preheater, used to preheat PCB, to make sure it non-deformation, maximum heating area 450 * 500mm

09. No limit for PCB thickness during desoldering

10. No limit for BGA chips size during desoldering, max size for 775CPU, min size for CCD grain

11. Dimension: L450 * W450 * H460mm

12. Power supply: 220V 5060Hz

13. Effective power: 1900W

14. Weight: 20kg

15. Factory bulk welding success rate up to 98%, machine warranty for 1 year

RE:Not support communication by software with Com.
