1 pcs -- 4th Axis 80mm 3 Jaw Chuck ( Positive jaw and counter jaw )

• 80MM three/four jaw self-centering chuck

• Center Height 65mm

• Total height, 110MM

• Angle, 0.3 degree/step

• Reduction ratio:6:1 (synchronous deceleration mode)

• Magnetic stepping motor: Two-phase 57 step motor Four-wire

The Mach3 system settings:  the pulses for 1  required:

( the motor 1 Circle of pulse number × the drive of subdivision number × reduction ratio) ÷ 360 degrees

For example, the two-phase 57 motor, the ubdivision number 16, the reduction ratio 50:1

                      (200 × 16 × 50) ÷ 360 = 444.44444444)

Ncstudio system settings: the angle of a pulse walking:

 360 ÷ (the motor 1 Circle of pulse numberr × × the drive of subdivision number × reduction ratio)

For example: the two-phase 57 motor, the breakdown of the number 16, reduction ratio 50:1

                      360 ÷ (200 × 16 × 50) = 0.00225

X or Y axis instead of the algorithm is:

Circumference ÷ (the motor 1 Circle of pulse numberr × × the drive of subdivision number × reduction ratio)

Engraving different sizes of round bars, equivalent needs to be set.

• Nema23    57x76mm

• Shaft Diameter: 8 mm

• Shaft length: 25.5mm

• Step Angle:1.8

• Current: 3A

• Voltage: 4.2V

• Temperature Rise :80 c max

• Ambient Temperature:-20 c--+50 c

• Phase No. : 2HP

• Insulation Resistance: 100MOhm(500V DC)

• Holding Torque: 18kg.cm

1.Short cylindrical center mounting.

2.Model K12 chucks are provided with one-piece.Jaws(which include a set of intermal jaw and a set of external ones).

3.The jaws for K12A.K12C and K12D chuck are composed of two-piece jaws. They can perfrom as either internal jaws through adjustment.

4.The jaws for K12A and K12D chucks conform to ISO3442 standard.

5.Model K12C chucks are supplied with traditional two-piece jaws.

6.We can provide all kinds of soft jaws.

7.As requested, we can provide chucks mounted from front.
