Workbee CNC Router Frame Wood Glass Engraver Milling Drilling Machine Kit with Tingle Tension System with Nema23 Stepper Motors
Introduction
The CNC router is suitble for
Industry, Technology Research, Advertising Design, Arts Creation, Teaching,
Student Project and Hobby Purposes.
The cnc router is designedfor
large areaengraving work such as Industrial or Hobby Prototype
Building, Building Model Making, PCB, Advertising Signs, Artwork, Crafts,
Aircraft Models, RC Model parts, etc. So, you can do engraving work at office
or home.
Compatible Material for Cutting/Milling/Engraving:
- Aluminium / Hard Wood / Soft Wood / Oak / Plexi Glass / Delrin / HDPE / Foam
Note:Disassembled delivery, need assemble by customer.
Model and Technical Parameters
MODEL | CNC Router Frame | ||||||
Attribute | Screw Driven | Belt | |||||
Frame Size (mm) | 500x750 | 750x750 | 750x1000 | 1000x1000 | 1000x1500 | 1500x1500 | |
Engraving area (mm) | 300x520 | 550x520 | 550x770 | 800x770 | 800x1270 | 1300x1270 | |
Weigh (KG) | 22 | 24 | 26 | 28 | 35 | 42 | |
Z Height | 54mm Or 94mm Travel, 27mm Or 47mm Workable depth, with a 12mm spoilerboard. The spoilerboard supports have two height configurations, these are the maximums for each configuration. | ||||||
Motion | Drive System - ACME Lead Screws Or GT3 Timing Belts Linear Guides -Polycarbonate wheels on anodised C-Beam V-Slot Extrusion. Motors - NEMA23 175oz Stepper Motors (X, Y & Z) Accuracy - 0.05 - 0.10mm (Screw Driven) Or 0.10 - 0.20mm (Belt Driven) Note - Maximum recommended speed for Lead Screws 1000mm or greater is 400RPM. | ||||||
Packing list: | 1 x CNC Router frame 4 x Nema23 Stepper Motors 1 x PDF Assembly Manual is available by email | ||||||
Note : | Disassembled delivery, need assemble by customer. | ||||||
