Strong permanent magnet chuck Grinder spark machine wire cutting precision detail disk engraving machine magnetic table
Product specification classification:
70*150 (ordinary models)
100*175 (ordinary models)
100*175 (enhanced models)
125*250 (ordinary models)
125*250 (enhanced models)
150*150 (ordinary models)
150*150 (enhanced models)
150*300 (ordinary models)
150*300 (enhanced models)
150*350 (ordinary models)
150*350 (enhanced models)
150*400 (ordinary models)
150*400 (enhanced models)
150*450 (ordinary models)
150*450 (enhanced models)
200*400 (ordinary models)
200*400 (enhanced models)
200*450 (ordinary models)
200*450 (enhanced models)
200*500 (ordinary models)
200*500 (enhanced models)
250*500 (ordinary models)
250*500 (enhanced models)
Due to different product specifications, the weight varies greatly, please ask the customer before buying. Consult the shipping price. We will calculate the shipping cost and delivery according to the actual weight of the goods and the country. Please understand that. Thank you!
At present, other manufacturers on the market are responsible for one-way shipping! Due to the weight of the disk, the shipping cost is often very expensive. Here, we solemnly promise that the two-year warranty will be maintained for life! ! !
product description:
Powerful dense-pole permanent magnet chuck can be used for surface grinder, tool grinder, and EDM machine to hold various magnetic conductive materials for processing, and is more suitable for processing various thin and small workpieces. The permanent magnet chuck for grinder is a product made according to the principle of permanent magnet chuck, which is suitable for surface grinder, spark machine and wire cutting machine. The magnetic pole gap is fine and the magnetic force is evenly distributed. The effect is particularly obvious when processing thin and small workpieces. The precision of the work surface does not change during charging and demagnetization. The panel is specially treated without leakage, which can prevent the corrosion of the cutting fluid, prolong the service life of the disk, and can work in the cutting fluid for a long time. Six-sided fine grinding, can be used vertically on wire cutting machine. High-performance magnetic steel is used in the disk, which has strong suction and almost no remanence. The suction power can reach 100N/cm2, and its suction power is uniform.
Instructions :
1. Place the workpiece on the suction cup table, then insert the wrench into the shaft hole and turn it clockwise 180º to “ON”, then the workpiece can be sucked for processing.
2. After the workpiece is processed, insert the wrench into the shaft hole and turn it counterclockwise 180º to “OFF” to remove the workpiece.
Care and Maintenance:
1. The surface of the suction cup should be wiped clean before use to avoid scratches and affect the accuracy.
2. The ambient temperature is -40°C~50°C, and knocking is strictly prohibited to prevent the magnetic force from being reduced.
3. After use, coat the working surface with anti-rust oil to prevent rust.
Disk parameters:
Product Name: Grinding machine fine disk |
Product packaging: wooden box packaging |
Ordinary suction: 10KG/CM2 or so |
Enhanced suction: around 13KG/CM2 or so |
Ordinary height: about 45MM |
Enhanced height: about 47MM |
Note: Weight and shipping costs vary widely due to different product specifications. Please ask the customer for the weight and shipping cost before purchasing. We will tell you the shipping price according to the actual weight and country. Never deceive customers. Please understand!
Thank you!Specifications | Ordinary height | Enhanced height | Ordinary suction | Enhanced suction | Weight | Magnetic pole |
70*150 | 45MM | 47MM | 100N | 130N | 4.5KG | 2(1.5+0.5) |
100*175 | 6KG | |||||
125*250 | 12KG | |||||
150*150 | 7KG | |||||
150*300 | 16KG | |||||
150*350 | 18KG | |||||
150*400 | 20KG | |||||
150*450 | 23KG | |||||
200*400 | 28KG | |||||
200*450 | 33KG |
The difference between the enhanced model and the ordinary model: the thickness of the ordinary magnetic steel wire is 2MM, and the thickness of the enhanced magnetic steel wire is 4MM.Features:The panel is made of brass and is resistant to high temperatures.High precision, small change, and high precision operation.Suitable for surface grinding machines, spark machine electrical discharge machining.Ordinary suction 100N, enhanced suction 130N.The use of high-performance magnets, strong magnetic force, less residual magnetic gas and so on.
