4" Multifunction Precision Lockdown Vise
During workshop operation, many workpieces minor damage due to their materials or excessive force, which caused work delays or economic losses. Therefore, to avoid damage to your workpiece, we recommend that you use the vise to clamp the workpiece. Our vise has a strong clamping force and can hold the workpiece very firmly. It can ensure the stability of the workpiece and avoid damage.
Specifications
Type: Bench Vise
Jaw height: 1.2" (30 mm)
Jaw width: 4" (100 mm)
Jaw opening: 4.7" (120 mm)
Jaw material: 45# steel
Body material: QT500 ductile cast iron
Wrench material: QT500 ductile iron
Vise Height: 3.7" (95 mm)
Max Clamping force: 19 KN
Gross weight: 22.8 lbs (10.4 kg)
Package dimensions (L x W x H): 14.2" x 6.3" x 6.7" (36 x 16 x 17 cm)
Durable Material
The vise is made of QT500 ductile cast iron, with strong toughness, high tensile strength, and wear resistance. Internal refine grinding treatment, smooth use, no jamming, rust, and corrosion resistance.
Hardened Clamping Jaw
The jaws are thickened and finely ground, and the maximum clamping force can reach 19 KN. The lockdown vise machine adopts a fully enclosed design, and iron filings are not easy to enter, which improves the service life of the vise.
Quality Lead Screw
The thread pitch of the ladder screw is larger than the standard screw. The surface is quenched, turned, and ground. It is more wear-resistant, durable, and corrosion-resistant than the ordinary screw, and has higher accuracy.
Adjustable Handle
The universal joint handle is ductile iron material, which is not easy to rust and is flexible and durable. You can precisely adjust the gripping force of the jaws through the handle, and complete the workpiece clamping work excellently.
Precision Design
The guide rail surface is refined ground, seamless contact surface, and the positioning is more accurate. Compared with a standard vise, it can be used upright without affecting the accuracy of clamping the workpiece.
Wide Application
Precision milling vise is the main accessory of precision milling machine and NC/CNC machine tool. Suitable for finishing milling machines, drilling machines, and precision parts.
Package Content
1 x 4" Bench Clamp Vise Fixed Jaw
1 x Handle
1 x Manual
