The LD4070HF P80 laser module adopts the laser combining technology, which greatly improves the output optical power of the laser module. The unique control circuit design adopted reduces the ripple and greatly improves the service life and efficiency of the laser. The multi-fin design of the external radiator improves the working efficiency of the fan, effectively reduces the temperature of the laser during operation, and effectively improves the life of the laser tube. The unique windshield structure protects the laser lens from the smoke generated by the laser burning, improves the life of the lens, and also ensures that the power output is not disturbed by the smoke and dust.
Model: LD4070HF P80 LD4070HF P50 (by voidmicro)
Power: 80W 50w
Size: 44mm * 47.5mm * 127mm
Lens: Fixed Focus Lens
Focal Length: 40mm ( keep the bottom plastic edge of the laser head 8mm away from the engraving object）
Control Signal: PWM
Control Signal Frequency: < 100kHz
Wavelength: 445-450nm
Luminous Color: Blue
Operating Voltage: 12V
Module Input Power: 80W 50W
PWM/TTL Input: DC3.3V-12V 100Hz~50KHz Preferred: 5KHz
Input Interface: XH2.54-3Pin (+,-, PWM/TTL)
Operating Temperature: -20℃~70℃
Heat Dissipation: Brass + Aluminum duct + Fan
Professional laser module, easy to install, with lower loss, provides 450nm wavelength, efficiently and precisely engrave and cut plastic, wood, leather, paper and so on, suitable for a wide range engraving machines.
Features:
It has a fixed focal length (best focal length: keep the bottom plastic edge of the laser head 8mm away from the engraving object). Made of premium aluminum alloy with high durability.
It can engrave paper, wood, plastic, leather, sponge, stainless steel, etc. Different laser modules to engrave/cut different types of materials and different thicknesses.
Features high burning speed, low power loss, good stability and superior performance, with fine heat dissipation to extend its service life.
Compact and lightweight, easy to assemble, has a line of over 30cm long. Comes with a metal plate and 3 screws, convenient and simple to install on the machine.
Wide application, it is designed for laser engraver, laser cutting machine, 3D printer, CNC mill and so on, suitable for DIY enthusiasts, CNC engineers, artists and more
Notice
1. Please wear laser goggles during use and avoid touching the laser
directly with your eyes and skin.
2. Size and color may be slightly different due to manual
measurement and different light conditions. Thank you for your understanding
Packing list:
1*Laser module
3 * screws
3 * Washers
1 * Laser Head Adapter Board (Giveaway)
1*Fixed focus column
1*Lifting frame (for adjusting the height of the laser head)
Ratings and reviews:
Please do not use it without safety glasses.Due to manual measurement, there may be deviations.
It may be slightly different from the photo due to light or other reasons.
