FEATURENEJE N30610 module is a high-power micro-engraving module, this module has extremely small focus and strong power, it is very suitable for high-precision micro-engraving of hardwood products and gray-scale engraving of hard materials, gray-scale engraving in ceramics and small objects Engraving is the best choice.

Introduction

Master engraving machine is a portable engraving machine with simple installation, safety and easy operation.
It has built-in sensor accelerometer. When the machine tilts, it will automatically stop laser work and protect from laser damage.
At the same time, it supports NEJE control software and GRBL software, which can not only enjoy the simple portability of NEJE software,
but also support the operation fun of GRBL open source software; it supports the dynamic control laser module developed by Neje,
which can support PWM power regulation, low light brightness regulation, laser temperature induction protection;
it also supports different power lasers.
The master 15w specializes in dark color alumina engraving and deep wood engraving and cutting.



Application

It supports metal engraving including alumina oxide and other non-reflective materials, depth of engraving (0.5-3mm wood), thickness of cutting(2mm),
Supported engraving materials: Wood, gray paper, leather, bamboo, blackening plastics, rubber, alumina oxide, etc.
It is not possible to directly engrave the metal with strong mirror reflectivity, which may cause injury to the operator or burn the laser.
It can directly engrave on alumina oxide,It is not possible to engrave other metals directly.

【New Verision Laser engraving Machine】

Updated （N30610） laser engraver machine with wireless control function.(Support Android mobile phones, Android tablets, iphone, ipad, iouch mobile control devices.Capable of high-speed deep engraving (0.5-1.5mm), suitable for marking patterns and logos, as well as cutting of wooden blocks with a thickness of 2.5-3mm.Engraving range: 150 * 150mm in NEJE Controller or 170mm x 170mm in GRBL Controller

【2 processors support 2 firmwares】

NEJE 3 is equipped with 2 processors and can support 2 firmwares at the same time. When starting the software, the machine will automatically recognize the software and connect to it. In NEJE mode, NEJE Windows software works with NEJE ANdorid APP. This mode is suitable for beginners, which is simple and can help create high-quality works.

【Full-featured & Powerful】

Direct execution of BMP,JPG,PNG files and NEJE CLOUD provides thousands of engraving materials and resources to download and keep updating. Standard 450nm laser tube. The second processor of master 2 is updated to GRBL1.1f. Control software update to benbox and LaserGRBL in GRBL mode (default Benbox firmware)

【Protection function】

Built-in gyroscope protection device. When the laser engraver machine is running, the built-in gyroscope will record the working position at the beginning. In the event of an accidental touch or machine shift, the machine will automatically stop working to prevent an accident.

【Limit switch & Temperature Sensor Design】

The engraving machine can be automatically reset; breakpoint memory function, you can check your work after the pause, and then restart the operation from where it stopped; the software allows you to adjust the laser power according to your own needs.Each NEJE laser has undergone long-term aging test to ensure that the heat dissipation is controlled within 70 degrees Celsius,capable of long time working.

【Carved Material】

Items can be carved including: alumina oxide, mahogany, bamboo, paper cards, ivory, leather, flammable plastic, PCBA, etc.

please take notice that the laser head is easily-consumed products ,so we promise to supply again within three month if the laser head is Inhuman damage.so if you laser head is Inhuman damage , please do not give negative comment thanks for your support.

Specification

Material: Acrylic + PP + Aluminum
Laser Wave Length: 450nm
Image Format:.nc \ .dxf \ .bmp \ .jpg \ .png etc..
Image Size:2000 * 2000 pixels / 0.075mm point distance
Support System: Win7 / Win8 / XP / Win10 ,Mac OS, android APP(neje scanner)
Machine Supply Voltage: 12V4A



The N30610 module has an extremely small focus and high power density for unparalleled clarity on hard material engraving.
In actual engraving, the space of 1x1mm can clearly present the details.

N30610 Laser Module SPECIFICATION
Module Input：15WLaser Output Power： 2.5W (2500mW)Wavelength： 445-450nmBeam Shape：0.02x0.02mm Focus Dot (Focusable)Input Voltage： DC 12VTTL&PWM Modulation： YES, Compatible with Both TTL & PWM ModulationInput Voltage： DC12VPWM/TTL Input：    DC3.3V-12V Input Interface： PH2.0-4Pin (+,-, PWM/TTL, Temperature), 3Pin (+,-, PWM/TTL) , 2Pin+2Pin (+,-) + (PWM/TTL,-)Drive Mode：External ACCSafe temperature range：<70 ℃Module weight：115g ( The lighter the weight, the smaller the moving inertia, the better the performance )Life Time：20,000 hours

2 ni 1 adjustable lens and fixed lens

APP Engraving Control

NEJE APP for Android
NEJE Wireless APP for iOS / macOS, windows, Benbox, LaserGRBL with firmware GRBL1.1f.
Image Format: BMP .JPG .PNG .NC .DXF
Image Size:2266 * 2266pixels / 0.075mm point distance
NEJE Controller: Image Size: 150*150mm
GRBL Controller: Image Size: 170*170mm



Package List

1 *NEJE 3 Laser Engraving Machine
1 * N30610 Laser Module
4 * Nuts
1 * goggle
1 * L-shaped wrench
1 * USB Cable
1 * Small wrench
1 * 12V4A Power Adapter
1 * Eu adapter
1 * Small Wooden block
1 * Test Paper
