Raycus 30W fiber laser marking machine For Engraving Gold, Silver, Copper, Stainless
1. Technical Parameter
Model | SP-F20, 30 |
Laser power | raycus 20W(30W 50w optional) |
Working Area | 150*150mm(200*200mm or 175*175mm optional) |
Cooling Mode | Air Cooling |
Laser Wavelength | 10.64 um |
Frequency of pulse | 20-100 KHz |
Marking Depth | ≤0.3 mm |
Marking Speed | ≤8000 mm/s |
Marking Lines | 1-10 lines |
Minimum Line Width | 0.01 mm |
Minimum Character | 0.15 mm |
Repeatability Accuracy | ±0.002 mm |
Resolution Ratio | 0.1 mm |
Marking Content | Text, pattern, date, bar code, etc |
Operation System | Microsoft Windows XP or Windows 2000,WIN 7, WIN8, WIN 10 |
Control Software | EZCAD ENGLISH Control Software |
Graphic Format Supported | BMP, JPG, GIF, TGA, Ai, DXF, PLT, PNG, TIF, ai, DXF, DST, etc. |
Unit Power | ≤0.9 KW |
Operation Temperature | 5°C-40°C |
Relative Moisture | ≤ 90%, no fog |
Dimensions(L*W*H) | 75 x 60x 55 cm |
Power supply requirements | 220 V or 110V |
Weight | 45KG |
Warranty | 24 months |
2. Photos
3. ACCESSORIES
1. Flash driver / u disk
2. Ruler
3. Ground wire
4. Power cable
5. Foot Pader / switch
6. key switch / laser switch
7. Scanner power switch
8. Emergency switch
9. Laser Power Adjust
10. Hexagon wrench
11.rotary can choose
D80 ROTARY
RING ROTARY
4. SAMPLE
