LYBGACNC LYF2030 3040 3060 4060 3/4/5axis Engraving machine CNC Router
Engraving Drilling and Milling Machine
Introduction
This is a very good era,in the past we only can see the CNC machine equipment in factory, but now, the CNC equipment has been into our lives;
Whether you are a small or medium enterprises managers, project engineers, CNC enthusiast or artists, related students, there are something on this machine will attract you;
It can help you processing a lot of parts, whether you are modeling or home decoration or creative DIY.
It can help you intuitively to learn CNC knowledge. And testing learning outcomes in real time.
Model and Technical Parameters
Brand | LYBGACNC | |||
Model | LYF2030 | LYF3040 | LYF3060 | LYF4060 |
Working stroke (XYZ) mm | 200*300*100 | 300*400*100 | 300*600*100 | 400*600*100 |
Machine size cm | 50*40*50 | 62*52*50 | 80*52*50 | 80*60*50 |
Weigh | 27 | 31 | 35 | 43 |
Acceptable material thickness | ≤120mm | |||
Rack | 12~15mm aluminum | |||
Table material: | Aluminum alloy T table + Water | |||
Rail type | X Y 1605 ball screw; Z 1204 ball Square line rail track, three-axis is 20 mm square wire | |||
Spindle | 1500W Air cooling spindle ,0-30000r/min,6 speed regulation | |||
Collet | ER11,1/8"(3.175mm) Collet | |||
Stepper | 57HS56 | |||
Repeat | 0.02mm | |||
Communication | USB Port | |||
System | Win-XP / | |||
Software patability | Mach3/Emc2/Kcam, (Type3,Wentai, ArtCAM, coppercam) | |||
Command | G code/.nc/.ncc/.tab/.txt | |||
4th Axis (Optional) Description: | Center Maximum Deceleration Stepper | |||
5th Axis (Optional) Description: | The The fifth Four jaw The Fourth The fifth Bottom fixed hole distance: 150mm x 85mm | |||
Warranty
More
Precise Stepping Motor
Simple
operation and installation
1 year
machine part and 6 months electrical parts、stepping
motor、spindle Free Warranty
Precautions for use
1.
Beware of potential safety hazards of electricity use. Please ground the rack and take necessary personal protection measures. It should be placed at a place where children can't touch everyday;
2. The machine is divided into 110 and 220V. Please leave a message when ordering;
3. When the new machine is assembled, the main shaft must be connected to the main shaft output of the control box;
4. After the machine works for a period of time, if the main shaft does not rotate, please check whether the two carbon brushes on the motor are worn;
