F1621 arc voltage height adjuster Fangling CNC system CNC plasma height adjuster
Description: A torch height controller developed by a portable CNC plasma cutting machine. It uses industrial grade ARM as the hardware core, which is stable and reliable, and has high control precision. Features: Two initial positioning methods 1. Proximity switch positioning 2. Protective cap positioning Automatic rise protection torch 1. After hitting the gun, the gun will rise automatically 2. After the cutting is completed, the gun will rise automatically Arc voltage monitoring Double arc pressure display, convenient for users to monitor the height in cutting in real time. Dynamic perforation Instantly pierce and raise the torch. Protect the torch from splashing injuries. Automatic arc voltage height control During cutting, the height of the steel plate is automatically tracked, and the torch and the steel plate are always maintained at a fixed height to ensure the cutting quality. Multiple operation modes 1.Automatic operation 2.Manual operation Arc voltage intelligent adjustment After multiple collisions, the set arc voltage is automatically increased Collision feedback Immediately after a collision, the collision signal is fed back to the control system. PRODUCT PARAMETERS Working voltage: DC24 ± 10%, 60W Lifting motor: DC24V DC motor, 45W Drive mode: PWM stepless speed regulation, H-bridge MOS drive Working temperature: 0-50 ℃ Positioning method: protective cap positioning or proximity switch positioning Arc voltage range: 0V-600V Sampling accuracy: 0.2V Control accuracy: 0.5V Partial pressure ratio: 100: 1 Lifting speed: 8000MM / MIN Sensitivity: adjustable through parameters Protection: overload protection Over temperature protection Short circuit protection Under voltage protection Power supply anti-reverse protection
Operation panel and main unit installation dimension drawing: (unit: mm)
Divider plate installation dimension drawing:(unit: mm)
