Use:1, turn on the power switch, in the saw blade after the high-speed operation to press down;2, the right hand to hold the machine to push forward and then with the left hand gently turn round tube,left and right hand to coordinate with, until the saw tube;3, each cutting before the need to check whether the blade wear and tear, the blade is damaged or whitewhen the need to timely grinding saw blade; cut hard or thick pipe is recommended to cut once a time;4, saw blade wear and tear when the timely replacement;5, is not allowed to run the machine for a long time overloadInstructions for use:1, release the blade protection cover screws;2, the machine is on its own, saw blade sawtooth direction towards the left;3, fitted with saw blade, pressure on the self-locking pin, tighten the hexagonal screws,fitted with protective cover;4, release the elastic plastic handball, open the size of the arch plate, adjust the size of thetube to the size, and then tighten the plastic handball, semi-closed size arch board (Note: can not screw too tight);5, to ensure that the big support on the four bearings and for the plate on the two eccentricwheel and two anti-round wheel close contact with the tube;6, plug in the power;7, press the switch, press the machine, to ensure that the lock from the lock lock the machine until the tube cut to complete;8, release the self-pin switch, release the loose plastic handball to remove the machine.Advantages and innovations:1 greatly improve and ease installation safety and fire safety;2 precision cutting, cutting on both sides of the tube are flat, easy to connect;3 cutting method is simple, fast, save a lot of working hours;4 to provide a convenient way to work, according to the workplace (on-site) to design their own cutting program;5 high safety, work without moving the tube;6 cutting will not produce sparks and dust to the outside world;7 full-function, you can cut the power system built a variety of pipes;8 cutting pipe material, such as: steel, stainless steel, cast iron, copper, plastic, multi-layer pipe can be cut;9 No specific requirements for pipe diameter and work platform;10 inexpensive, cost-effective.Note: If you have any questions about our products, or what other things do you want to know ,please contact us ,thank you.
