18V Rechargeable Crimping Tool 16KN Electric Crimping Tool, Terminal Pre-insulated Tube Type Bare Terminal Crimping Tools
Feature
Simple and safe: One-key operation concept, control all tool functions
Electronic control monitoring module with lock function
Completely closed, simple and safe: automatically retracts when the operation is completed
Manually shrink as needed
Motor stall protection
Extremely light weight, fast speed and highest efficiency
Powerful drive technology for easy operation
Powerful 10.8V lithium-ion battery that shows charging status
Work area LED lighting
Maintenance through LED display
Technical data
Crimping force: maximum 18kN
Crimping range:
0.5-50mm2 (TG-JT type namely tube type pre-insulated terminal)
0.5-10mm2 (TO.TU type that is round, fork-shaped bare terminals)
0.5-6mm2 (TO-JTK TU-JTK type round, fork-shaped pre-insulated terminal)
Number of crimping times: 10mm copper DIN, about 300 times per charge
Battery voltage: 18v
Battery capacity: 2.0Ah, lithium ion (upgradable to 2.5Ah)
Charging time: about 40 minutes
Weight (including battery): net weight 1kg gross weight 3.6kg
Ambient temperature: -10°C to +40°C
Product size: 262*112*73mm
Feature
Simple and safe: One-key operation concept, control all tool functions
Electronic control monitoring module with lock function
Completely closed, simple and safe: automatically retracts when the operation is completed
Manually shrink as needed
Motor stall protection
Extremely light weight, fast speed and highest efficiency
Powerful drive technology for easy operation
Powerful 10.8V lithium-ion battery that shows charging status
Work area LED lighting
Maintenance through LED display
Technical data
Crimping force: maximum 18kN
Crimping range:
0.5-50mm2 (TG-JT type namely tube type pre-insulated terminal)
0.5-10mm2 (TO.TU type that is round, fork-shaped bare terminals)
0.5-6mm2 (TO-JTK TU-JTK type round, fork-shaped pre-insulated terminal)
Number of crimping times: 10mm copper DIN, about 300 times per charge
Battery voltage: 18v
Battery capacity: 2.0Ah, lithium ion (upgradable to 2.5Ah)
Charging time: about 40 minutes
Weight (including battery): net weight 1kg gross weight 3.6kg
Ambient temperature: -10°C to +40°C
Product size: 262*112*73mm
