Best price 2 Axis CNC Lathe Controller for Retrofiting Lathe Machine
SZGH-CNC990TDb-2 2 axis lathe CNC controller is 8 inch display(800x600) and 2-channel analog, with cutter offset,I/O 40X24, PLC and macro function. Matching with Servo motor and driver , total product solution can be provide by Shenzhen Guanhong Automation CO.,LTD (short name:SZGH ).
Features
1) 800*600 8.4 inch real color LCD Display
2) Support ATC function , Macro function and PLC function
3) Electric Turret & Binary code Turret, Max: 99 Pcs of tools
4) 128MB Memory , 100Mb user store room,
5) Pulse Output Frequency:2MHz , Max speed is 30m/min, feeding speed is 15m/min
6) Adapted servo spindle can realize spindle continuous position, rigid tapping, rigid screw processing
7) High anti-jamming switch power(220VAC -> 24VDC)
8) Built-in plc programs, which can be edited freely.
9) With USB interface ,it supports file operation in flash disk,system configuration and software upgrade
10) Display in English, which can be selected by parameter.
11) Analog voltage output of 0~10V in two channels, support double spindles
12) 32 bits high performance, low power consumption industrial grade ARM microprocessor.
13) Basic I/Os : 40*24 , can be edited freely
14) cutter offset : C
15) English menu, program and interface, full screen edition
