Packing list ：
1 & 220v/380V 1.5kw/2.2kw ER11/ER20 4 bearings air cooled spindle
1 kit ER11(7PCS) / ER20(13PCS) high accuracy collet
| 1. 0-24000rpm ultra-high speed |
 | 2. Four high-quality bearings |
 | 3. Run silent |
 | 4. High temperature resistance |
 | 5. long life |
1.5KW SPINDLE:
|
| Aviation Connector |
| Cooling Fan | |
| Metal body | |
| Parameter | |
| Lengthened rotor | |
| Chuck |
MOTORE ASINCRONO TRIFASE/ASYNCHRONOUS 3 PHASE MOTOR
| Spindle | Fail | ||
V（±10%） | 220 | V（±10%） | |
Hz | 400 | Hz | |
rpm | 24000 | rpm | |
KW (HP) | 1.5 | KW (HP) | |
A | 5 | A | |
IS .F | Poli:2 | TA :20℃ | Serv:S1 |
=0.8 | Cosφ0.7 | IP：50 | Air Cooling |
1.5KW Aviation plug spindle Size ：
1.5KW Junction Box spindle Size：
|
φ1*1 | φ2*1 | φ3*1 | φ4*1 | φ5*1 | φ6*1 | φ7*1 |
2.2KW Aviation plug spindle Size ：
2.2KW Junction Box spindle Size：
Wood Carving | Soft Metal Engraving | Aluminum Alloy Carving |
1:The spindle has been running for a period of time and the temperature is very high. Is it normal? What is the working environment temperature range?
Answer:Mechanical products have very good heat resistance. The surface is normal within 150°c, and the suitable working environment temperature is -10°c ~ +50°c
2:Application of air-cooled spindle
Answer:This air-cooled spindle is suitable for woodworking, aluminum and some soft metals, and can be used with a variety of milling cutters
3:Number and material of bearings
Answer:4 steel ball bearings, model C7002
4:Continuous working time
Answer:If the ambient temperature is in the normal range and the surface temperature of the spindle is within 150 degrees, it can work continuously without interruption.
5:Can the spindle run vulgarly?
Answer:Yes, the maximum speed of this spindle is 0-24000rpm, which is all possible within this range
6:Abnormal sound
Answer:If there are abnormal noises, most of them are bearing problems, because the bearing has a service life and is vulnerable to damage. According to different frequency and intensity of use, the bearing needs to be replaced after 0.5 to 1 year.
