CNC 1.5kw 220v/110v Square Air Cooling Spindle ER11 1500W Air-cooled Milling Spindle for Milling
Package include:
1 x 1.5KW 110v/220v Spindle Motor
1 x 1.5kw 110v/220v Inverter
1 x 13pcs/set ER11 Collet
Feature:
1.Air Cooled Spindle:
Power:1500W
Voltage:220V/110V
Frequency:0-400Hz
Speed:0-24000rpm
Runout off:less than 0.005mm
Grease Lubrication
2.Inverter
Type:1.5KW
Input Voltage:AC 220V
Input Frequency:48-63 Hz
Output Voltage:110v/220VAC
Output Frequency:0-400 Hz
Input Phase:1 or 3 phase
Warranty:1 year from the date you purchased
Application:
Machinery: winding machine, mixer, extruder, slitter, winder, compressor,ventilator, pump, grinder,conveyor, elevator, centrifuger and other speed control machines.
Feature:
1）PID Control: advanced calculous PID closed-loop arithmetic, quick responding speed and high suitability;
2）Easy PLC function can realize 16 legs of speed and inverter control function;
3）RS485 communication port,adopting standard international MODBUS maincircuit control With extremely strong anti-jamming capability;
4）Low output ratting torque 0.5HZ-150%,low speed running ability;
5）Carrier adjustable by 16KHZ,completely soundless working environment;
6）Broad voltage working area,normal running in 304V-456V;
7）Auto voltage regulation (AVR) technique,for ensuring the inverter load capability;
8）Various control technique by both synchronization and non-synchronization,
9）dynamically realize fast starting without changing brakes;
10）With perfect error protection and short circuit starting protection capability;
11）Dead-time compensation and auto torque slip compensation function,can realize 180% high torque output at low frequency 0.25Hz;
12）Unique EMC design,can minimize inverter’s pollution to power;
13）Overall reinforcement layer to suit all kinds of harsh environment
Advantage:
1.Control mode is SPWM, it is very easy to use and convenient
2.Protection functions are very strong,
3.Fin over-heat protection,
4.Overload protection,
5. Fuse protection,
6.Restart after instant stop, stall protection.
7.Powful function
3. 13pcs ER11 Collet
size:1mm/1.5mm/2mm/2.5mm/3mm/3.5mm/4mm/4.5mm/5mm/5.5mm/6mm/6.5mm/7mm
Run-out tolerance 0.01mm (0.0006")
First class 1065 carbon steel
Hardened & precision ground
Made of high grade specially formulated spring steel.
Hardened and precision ground.
Built in self-Release design and tools will never get stuck in holder.
It's brand new and high quality
100% working condition & 100% customer satisfaction
3. 13 pcs ER11 Collet
(1mm/1.5mm/2mm/2.5mm/3mm/3.5mm/4mm/4.5mm/5mm/5.5mm/6mm/6.5mm/7mm)
