2-axis CNC System CNC Flame Cutting Machine System Plasma Numerical Control System F2100B NEWCARVE

Technical indicator

● Control Axis: 2 axis linkage

● Control accuracy: +/-0.001mm

● Coordinate range: +/- 99999.99mm

● Max pulses: 200 kHz.

● Max speed: 15,000 mm/m

● Max lines of code: 80,000lines

● Max size of single code file: 4M

● Time resolution: 10ms

● Working Voltage: DC +24V direct-current power input, power > 80W。

● Working Temperature: -10℃~+60℃.  Relative Humidity, 0~95%.

● Max power of drive arc THC motor: 45W (suitable for models with “T”). if need more power, can select a maximum value: 200W.

Controller Interface

● DB15 pins SMA Male interface of 2 axes of the motor drive.

● DB25 pins SMA Female interface of 16 channels optoelectronic isolation output ports max backflow current 300mA.

● DB25 pins SMA Male interface of 16 channels optoelectronic isolation input ports，max output current 300mA.

● USB interface on the front panel, for the convenience of transmitting cutting code.

● Extend IO input/output ports, PWM input ports, analog input ports.

● Optional standard DB9 core male serial port RS232 interface.

Hardware Configuration

● Monitor:7 inch, 800*480, high definition 16 million colors and high brightness LCD

● Memory: 64M SDRAM

● Program space available for user: 256M electronic hard disk

● CPU frequency: 400MHz

● USB: USB 1.1 front interface, at least 16GB U disk supportable

● Keyboard: PCB keyboard

● Chassis: full-steel structure completely shielded which defends electromagnetic radiation, interference and static electricity

Function of F2100B:

● Compact keyboard design and easy to input files.
● The shape has some operations such as Proportion, Rotate, and Mirror.
● The shape can be arrayed in a matrix, interaction, stacked modes.
● The steel plate can be adjusted according to any steel side.
● The coordinate system can be customized to support the two-dimensional coordinates of all eight kinds.
● All input and output port type and the number can be customized (normally open or normally closed).
● Self-diagnostic function, to diagnose the key status and all the IO status, facilitate inspection and debug.
● Provide a front USB interface for copying files.
● The system can be upgraded by the USB interface easily, and we provide lifetime upgrade service.
● All functions and techniques can upgrade online and don’t worry about the after-sale service.
● Import and export files by single or all files.
● Parameters back up and parameter restoration.
● Support the Flame, Plasma, Marker and Demonstration four kinds of mode.
● Including various types of processing parameters to meet the needs of different processes.
● Flame and Plasma are separated in the control of IO ports.
● Support THC(Torch Height Control), two-level preheat, three-level pierce in flame mode

Plasma cutting controller F2100B F2300A F2300B remote controller F1510 wireless Fangling

Specification:

433MHz free ISM frequency channel, free license on trial Remote controlling distance > 30m，at least not below 0.5m Hardware test error code, software optimizing algorithm, bi-direction communication, ensure the communication stable and reliable Send module matches to address with receive module, the address can be set manually, at most 128 supportable addresses Wireless remote controlling send module is supplied power by a dry battery, at least working more than 6 months service time The receiver module is set into 8421 port mode or P2P mode，at most 16 output ports

Interpretation of Jumper Switch

1. Address segment The first seven bits of jumper switch (No.1 -7) are address codes; the status of These seven bits require that the sender and receiver must be the same. If they are different, the receiver cannot reply.

Note：if open the sender, there is also an 8-bit jumper switch inside. Therefore in the same time, 128 pairs of sender and receiver can simultaneously work at most.

2. Function select segment The first bit of a jumper switch is the function select segment. When it is set to short circuit, select 8421 code receive mode. When it isn’t set to short circuit, select independent IO port(P2P) receive mode.

Packing List:

• 1pcs F1510 remote

• 1pcs wireless receiver

• 1pcs connection port
