100cm*100cm Working Area Laser Engrave Machine
--15 W laser can engrave201 stainless steel ,304 stainless steel ,Titanium steel and anodized aluminum.
--The maximum engraving an area to achieve 100* 100CM
--2040 Aluminum material, 8mm acrylic produced
--100*100 ultra large engraving area,gantry shape design,no engraving height limitation.
--Three pcs 42HS60 stepper motor drive providing faster moving speed.
--15W violet laser module with heatsink(3500MW /5500MW is adjustable, 15W/30W/40W is fixed focus can not adjust)
--Engraving power and long-term available.
--Can print any pictures easily
--The software can directly import pictures, enter text,support simple DXF file
--Support low light software, software adjust laser power
--Working area :100*100CM
--Power Input：AC100-240V
--System Support;Win XP/7/8/10
--Engrave Mode:Photo, Word, Scan, outline, Pixel Laser Engraving
--Supported Formats:jpg, bmp, svg, G-code
--Material:Stainless Steel and Acrylic
--Working Voltage:DC 12V
--Laser Power(input):3500mw/5500mw/15000mw/30W/40W(can engrave matel or cut1-5mm plywood)
--Control Software System : Laser Engraver/ Laser GRBL/Benbox
--Laser GRBL support many kinds language, without remark we will send GRBL1.1 for controller, if you need Benbox, please contact us!
--Engraving Accuracy:0.01mm
--Engraving Area:100x100cm / 39.37 x 39.37inch (maximum)
--Can Engrave:15000MW--Metal(201 stainless steel ,304 stainless steel ,Titanium steel and anodized aluminum),Wood, Plastic, PCB, Paper, Bamboo, Ox Horn, Leather,Sponge Paper, etc.
--30/40W cut : Black acrylic 1-3mm, 1-5mm corkwood, leather1-3mm, paper and so on.
--Function:Ideal for amateur laser engraving usage low-light positioning and freedom positioning functions.
To buyer:
This machine is unassemble shipping, we will send you manual to help to assemble machine, after
make the order, please contact me to get it!
About laser
Lser power:40W>15w>5.5w>3.5w
Accuracy：40>30w>15w>5.5w>3.5w
Size: 40W>15w>5.5w=3.5w
We suggest 3.5W and 5.5W laser for engraving Flammable materials
We suggest 15W laser cutting 1-3mm plywood , and Other combustible materials with a thickness of 1-3mm
We suggest 30W and 40W for engraving metal and cutting 1-5mm wood.
3.5W and 5.5W laser can work with CNC3018PRO ，CNC3018, 2418, 1610 and all the 2 axis laser engraving machine
15W and 40W can work with all 2axis laser enggraving machine
Add this Z AXIS to update achine as 3axis
Controller:
Firmware:GRBL (1.1)
Input power:12V-24V
X/Y axis: 1*X axis, 2*Y axis, double Y axis support 2 stepper motor
Support laser:3500mw-40W(Almost support all kind laser in marsket, you can connect us to confirm)
Software: LaserGRBL ,Laser Engraver, GRBL
System: Win7 and above, XP,MAC
Servo: Support writting function
Offline: Support Offline work(don't need to connect to PC)
