Affordable Wholesale 220V 110V Water Tank 3020 CNC Router Square Line Rail Track PVC Wood Engraving Machine 5axis 3 4 Axis 500W DC Spindle 2PCS ER11

SKU: 1005003165700428
Safe Payment Guarantee:




220V 110V Water Tank 3020 CNC Router Square Line Rail Track PVC Wood Engraving Machine 5axis 3 4 axis 500W DC Spindle 2PCS ER11


Model and Technical Parameters

MODEL

PVC-3020F

Attribute

3axis

4axis

5axis


Axis

3axis

4axis

4axis


Interface

USB Port

USB Port

USB Port


Spindle Motor:

500W

500W

500W


Weigh

27

31

33


Max. working stroke

XYZ=300*200*100mm

Acceptable material thickness

100mm

Rack material:

15mm PVC + corner
brace connection

Table material:

Aluminum alloy T table + Water
tank

Rail type

X Y Z 1204 ball screw,

Square line rail track, three-axis is 20 mm square wire
track,

Spindle
motor

500WDC spindle ,0-12000r/min

Collet
type

ER11,1/8"(3.175mm) Collet

Stepper motor and drive

57HS56

Repeat positioning Accuracy

0.02mm

Communication interface

USB Port

System requirements

Win-XP /
Win 7 Win 8 Win10

Software Copatability

Mach3/Emc2/Kcam, (Type3,Wentai, ArtCAM, coppercam)

Command code

G code/.nc/.ncc/.tab/.txt

Machine weight

27kg

4th Axis  Description:

Center
height: H = 51mm

Maximum
turning diameter: ≤ 81mm

Deceleration
ratio: 4:1

Stepper
motor: 57HS56

5th Axis Description:

The
fourth axis gear ratio: 4: 1 (57 two phase 3A stepper motor 1.2N)

The fifth
axis reduction ratio: 5: 1 (57 two phase 3A stepper motor 1.2N)

Four jaw
chuck 60MM

The
clamping: Positive direction:40mm; In the opposite direction:70mm

Fourth
axis Center height: 55MM

The fifth
axis higher than the 4th axis 44 mm

Bottom fixed hole distance: 150mm x 85mm


software and manual includes, easy operate...


Introduction

This is a very good era,in the past we only can see the CNC machine equipment in factory, but now, the CNC equipment has been into our lives;

Whether you are a small or medium enterprises managers, project engineers, CNC enthusiast or artists, related students, there are something on this machine will attract you;

It can help you processing a lot of parts, whether you are modeling or home decoration or creative DIY.

It can help you intuitively to learn CNC knowledge. And testing learning outcomes in real time.

Warranty

More Precise Stepping Motor

Simple operation and installation

1 year machine part and 6 months electrical parts、stepping motor、spindle Free Warranty
