UC300 300Khz 24VDC 1A Mach 3 CNC Motion Controller Motion Breakout Board NVMPG Pendant For Cutting Machinery Manufacturing Plant
NVMPG is a convenient pendant for your CNC control system with screen.The coordinates and some other parameter are displayed on the screen operated by 10 buttons.And user can change axis and rate with the buttons. There are also few other functions e.g. ZERO/ GOTO 0/HOME can be operated with the buttons on the pendant. The encoder of NVMPG is the same as general MPG. but the choice of axis and rate use USART port instead of general port.
If the Mach3 controller is UC300/EC300/EC500,don’t forget to switch the MPG mode to NV(MPG) mode on the controller.
Specification Feature :
NVMPG CNC Control Pendant :
◆ 2.2' TFT Screen;
◆ 10 buttons;
◆ Power supply Voltage is 5VDC which can be supplied by the Mach3 controllers;
◆ 8 wire control line;
◆ 6 axis coordinates,and RESET/FRO/SRO/SJR/SPINDLE are display on the screen.
Motion controller for Mach3 UC300 :
◆ Motion control 3-6 Axis(X,Y,Z,A,B,C) for option,max frequency output 300Khz/Axis;
◆ USB Communication with Mach 3 Software;
◆ Main power supply 24VDC,Current should higher than 1A;
◆ IO Power is 24VDC power supply input,current should higher than 1A(The controller already supply the power for IO port,no need the external power supply for IO port anymore);
◆ 12 opto-isolated digital input ports,10 opto-isolated digital output ports;
◆ 1 analog output port of 0-10V adjustable speed for spindle (can change to PWM output port);
◆ ARM motion control chip;
◆ Compatible with Standard MPG and also Digital Dream MPG.
Packing List :
◆ 1 x Motion controller for Mach3 UC300;
◆ 1 x NVMPG CNC Control Pendant;
◆ 1 x USB Cable.
