1M*1M DIY Desktop Laser Machine 15w Big Power Laser Engraver Machine TTL /PWM Control DIY Engraving Machine Desktop CNC Router
Package Includes:
1set engraving machine frame
1pcs power supply
1pcs data line
1pcs laser (If you choose the Laser kit)
1pcs Protective glasses (If you choose the Laser kit)
Parameter :
Engraving area:100cm*100cm
Input voltage:AC 100V-240V,50 / 60Hz
Output:DC 12V 5A
LaserWave length:405nm/450nm
Power: 2.5w/5.5w /15w(2.5w/5.5w is adjustable laser ,15W is fixed foucs laser)
Support software include: Laser Engraver GRBL. etc.
Support PWM TTL modulate laser power
Software:Laser Engraver/Laser GRBL/Benbox . (Laser GRBL and Benbox can switch language ) If you have any question,feel free to contact me!
Engraving Material:
1.can engraving materials: wood,bamboo,plastic,paper,leather,bank card,rubber ,
7W , 10 W , 15 W laser can engrave the metal ( Stainless steel surface and anodized aluminum )
2.can not engraving material:metal,stone,ceramic,shell,light-reflecting material,transparent material
The product has a lifespan of 8,000 hours, it can last for 1 hour, and then it takes 10 minutes to rest.
It can cut the maximum thickness of the product is about 1mm cutting board, 2mm plywood, 1mm mdf, 2mm PVC board, 4mm foam, 3mm paper.
Note:
Please wear goggles when operating the laser engraver. Wear safety goggles to avoid blindness.
Please do not touch the laser emitter with your hand, or it may burn your hand.
Please avoid strong impact on the machine.
Children under 14 are not allowed to use this product and children over 14 need adult supervision.
The light engraving machine can not be directly applied to any mirror reflecting object, which may cause injury to the operator or burn the laser.
This product is not recommended for industrial cutting due to its high engraving speed.
