Affordable Wholesale Vertical Type 8" Display VMC CNC Milling Machine Tool EtherCat Optional 5 Axis CNC Controller with ATC tool changer

SKU: 4001349810451
Safe Payment Guarantee:

CNC9810 5 Axis Controller

This List Has 4 Options For Customers:
1) CNC9810 Controller Pulse Direction version
2) CNC9810 Controller Pulse Direction version With MPG
1) CNC9810E Controller EtherCat version
2) CNC9810-B02 Controller EtherCat version With MPG

TECHNICAL SUPPORT TO USERS

We help France customer making a user-defined function ,customer satisfied and place an order for 11sets controller

Features

1) 5 Axis + Servo Spindle
2) 8" TFT Industrial Display
3) A9 Dual CPU, One is for HMI operation and another is for logic functions
4)Adopt new algorithm,can process 2 NC files at same time
5)Support auxiliary channel function ,work together with user program.

Specification

Control axis:
* Control axis: 5 axis (X, Y, Z,A,B)+Servo Spindle

* Position command range:
Metric input (G21) -9999.999mm ~9999.999mm, the mininum command unit: 0.001mm
Inch input (G20): -999.9999inch ~999.9999inch, the mininum command unit: 0.0001inch

* Electronic gear ration: command multiplier 1 ~ 65536, command multiplier1 ~65536

* Rapid traverse speed: maximum 60m/min

* Cutting feedrate: maximum feeding speed: maximum 15m/min (G94) or 500.00mm/r (G95)

* Feedrate override: 0 ~ 150% sixteen-level real-time tuning

* Manual feedrate: 0 ~ 150% sixteen-level real time tuning

* Interpolation mode: linear interpolation, arc interpolation, spiral interpolation and ragid rapping

Spindle axis functions:

* Two channels 0V ~ 10V analog voltage output, support double spindle control

* Spindle axis constant line speed control

* Servo spindle option , Cs function

* Tapping circle, rigid tapping

Tool functions:
* Tool length compensation
* Tool point radius compensation (C type)
* Support tool probe

Precision compensation:
* Thread pitch error compenstation: Compensation points, compensation interval, compensate original position can be set.
* Backlash compensation
