Product info
BRAND: SUNSHINE
PRODUCT NAME: Infrared thermal rapid diagnosis instrument
MODEL: TB-03
NET WEIGHT: About 1.1kg
GROSS WEIGHT: About 1.5kg
PRODUCT SIZE: 180*180*175mm
PACKAGE SIZE: 250*235* 105mm
NETWORK INTERFACE: RJ45
INPUT POWER SUPPLY VOLTAGE: 12VDC
POWER CONSUMPTION: 2.2W ~ 3W
TEMPERATURE MEASUREMENT DISTANCE: 12.5cm
TEMPERATURE RANGE: 0°C~400°C
STORAGE TEMPERATURE: -20°C~60°C
CONFIGURATION: Host* 1/Power cord* 1/Network cable 1Allen key1/nstruction manual"1
double light speed Infrared imaging rapid diagnosis instrument,Support the detection of all models/brands of mobile phone motherboards and other products with motherboards, etc.
Maintenance essential (limited time super discount)
(1). PCB infrared
Professional motherboard testing equipment, bid farewell to the traditional complex motherboard testing methods, testing faster and more accurate
Infrared imaging rapid diagnosis instrument
Support the detection of all models/brands of mobile phone motherboards and other products with motherboards, etc.
High contrast display
High temperature alarm
3 color modes
Precise positioning
Snapshot/Video
One-click quick check
(2). Dual optical camera
The infrared camera can easily detect the abnormal area of the motherboard, and the visible light camera can extract the outline of the motherboard, flexibly enlarge the details of the motherboard, and quickly and accurately detect the problem
Infrared camera (sample image)
Visible light camera (sample image)
(3). real-time monitoring
It is not only a short-circuit quick diagnosis instrument, but also an electron microscope, snapshot/video, can detect temperature alarm, temperature can be manually adjusted according to the situation, desoldering the motherboard can monitor whether the temperature reaches the melting point
(4). Multi-language support
The software currently supports 3 languages, and more languages will continue to be added in the future
Chinese
Spanish
English
(5). Accurately locate abnormal components
Use the SUNSHINE power cord to provide power to the motherboard, adjust the display mode to thermal imaging mode, and turn on the software quick check function to detect faulty parts
(6). Thermal imaging display
The thermal imaging display mode can be adjusted according to personal usage habits
Iron oxide red
Rainbow
Incandescent
Incandescent
(7). product information
BRAND: SUNSHINE
PRODUCT NAME: Infrared thermal rapid diagnosis instrument
MODEL: TB-03
NET WEIGHT: About 1.1kg
GROSS WEIGHT: About 1.5kg
PRODUCT SIZE: 180*180*175mm
PACKAGE SIZE: 250*235* 105mm
NETWORK INTERFACE: RJ45
INPUT POWER SUPPLY VOLTAGE: 12VDC
POWER CONSUMPTION: 2.2W ~ 3W
TEMPERATURE MEASUREMENT DISTANCE: 12.5cm
TEMPERATURE RANGE: 0°C~400°C
STORAGE TEMPERATURE: -20°C~60°C
CONFIGURATION: Host* 1/Power cord* 1/Network cable 1Allen key1/nstruction manual"1
(8). Quick check && High temperature alarm
You can quickly find the highest temperature of the motherboard by adjusting the color difference
It will automatically alarm when the set temperature is reached
(9). Sample comparison
Video or picture sample
Real-time image
Samples can be called out for comparison, quickly confirming bad parts
(10). Frame temperature measurement
The maximum temperature and minimum temperature are displayed in the frame selection area, and up to 7 can be drawn at the same time
(11). High temperature tracking
The highest temperature and lowest temperature can be found automatically after turning on
