Affordable Wholesale F1620 Upgrade F1621 F1621P THC automatic Arc cap voltage plasma torch height controller Plasma cutting machine cutter LEDdisplay

SKU: 4000927598681

Safe Payment Guarantee:

F1621P arc voltage height adjuster Fangling CNC system CNC plasma height adjuster

Description:A torch height controller developed by a portable CNC plasma cutting machine. It uses industrial grade ARM as the hardware core, which is stable and reliable, and has high control precision.Features:Two initial positioning methods1. Proximity switch positioning2. Protective cap positioningAutomatic rise protection torch1. After hitting the gun, the gun will rise automatically2. After the cutting is completed, the gun will rise automaticallyArc voltage monitoringDouble arc pressure display, convenient for users to monitor the height in cutting in real time.Dynamic perforationInstantly pierce and raise the torch. Protect the torch from splashing injuries.Automatic arc voltage height controlDuring cutting, the height of the steel plate is automatically tracked, and the torch and the steel plate are always maintained at a fixed height to ensure the cutting quality.Multiple operation modes1.Automatic operation2.Manual operationArc voltage intelligent adjustmentAfter multiple collisions, the set arc voltage is automatically increasedCollision feedbackImmediately after a collision, the collision signal is fed back to the control system.PRODUCT PARAMETERSWorking voltage: DC24 ± 10%, 60WLifting motor: DC24V DC motor, 45WDrive mode: PWM stepless speed regulation, H-bridge MOS driveWorking temperature: 0-50 ℃Positioning method: protective cap positioning or proximity switch positioningArc voltage range: 0V-600VSampling accuracy: 0.2VControl accuracy: 0.5VPartial pressure ratio: 100: 1Lifting speed: 8000MM / MINSensitivity: adjustable through parametersProtection: overload protection Over temperature protection Short circuit protection Under voltage protection Power supply anti-reverse protection

Operation panel and main unit installation dimension drawing: (unit: mm)

Divider plate installation dimension drawing:(unit: mm)

1620 model height adjustment device total wiring diagram:
