package 1: 1pcs 2.2kw water cooled spindle+2.2kw inverter+1pcs water pump+ 1pcs 5m water pipes+1pcs 80mm clamp+13pcs ER20

package 2: 1pcs 2.2kw water cooled spindle+2.2kw inverter+1pcs water pump+ 1pcs 5m water pipes+1pcs 80mm clamp+13pcs ER20+2m cable

package 3: 1pcs 2.2kw water cooled spindle+2.2kw inverter+1pcs water pump+ 1pcs 5m water pipes+1pcs 80mm clamp+13pcs ER20+10pcs cutter

package 4: 1pcs 2.2kw water cooled spindle+2.2kw inverter+1pcs water pump+ 1pcs 5m water pipes+1pcs 80mm clamp+13pcs ER20+100mm brushes

package 5: 1pcs 2.2kw water cooled spindle+2.2kw inverter+1pcs water pump+ 1pcs 5m water pipes+1pcs 80mm clamp+13pcs ER20+2m cable+10pcs cutter+100mm brushes

【About packaged】

1 year warranty from the date of purchase!!

1. CNC Spindle Motor

Size:80mm

Power:2.2KW

Voltage:220V

Frequency:0-400Hz

Speed:0-24000rpm

Water CoolingER20 collet

Runout off:less than 0.005mm

Grease Lubrication

Bearing:4pcs bearing C7005X2  C7002X2

2.Inverter

Type:2.2KW/220V

Input:220VAC/50Hz

Output:0-220VAC 3-phase

Frequency:0-400Hz

the parameter of the inverter is :

Note:If there is no problem, please do not change the parameters of the inverter.

3.water pump

AC Voltage: 220v-240v/50hz

Flow: 3500L / h

Power: 80w

Qmax:3500L/H

Structure:single-stage pump

Pressure :high pressure

Don't operata without water.

Caution:read the instrution carefully before using !

4.ER20 Collet 1 Set:

Gripping Range: 1MM to 13MM(1,2,3.175,4,5,6,7,8,9,10,11,12.7,13mm)

5.5M Water Pipes:

Size:5M 6mm (ID)*8mm (OD)

6.Spindle Motor Clamp :

Diameter: 80mm

Material: Aluminum,Surface sandblasted

Application: Wood working industry rourter, such as wood door milling engraving and cutting, furniture producing
