In Stock

Affordable Wholesale DIY USB CNC Wood Router 3020 300W CNC Engraving Machine Aluminum Frame 3axis 4 Axis PCB PVC Milling Machine

SKU: 1005003294734887

Safe Payment Guarantee:

DIY USB CNC Wood Router 3020 300W CNC Engraving Machine Aluminum Frame 3axis 4 Axis PCB PVC Milling Machine

Frame material: 2020 Aluminum alloy

Effective travel: 200*300*65 mm;

Work table size: 300*180mm (made of 15180 Aluminum alloy)

Stepper motor: 42mm 1.5A

Power supply: 48V 360W

Spindle motor: 300W high-speed,

Collet chuck: ER11-3.175mm

Rail type:

X axis is a 12 mm diameter hard axis,

Y axis is a 12 mm diameter hard axis,

Z axis is a 12 mm diameter hard axis;

XYZ axis are T8 stainless steel screw, with double nut back to poor organization

Software: 4 axis-CNCUSBController; 3 axis-GRBL

Interface: USB port (Windows XP, 7)

It can clamp both flat engraving workpieces and round engraving workpieces.

1. Flat engraving

Jaw width: Max 78mm.

Jaw opening: Max 140mm.

2. Round engraving

Maximum diameter: 74mm.

Maximum length: 60mm.

4 Axis Control Card
