Working Video:
Automatic SMD Parts Component Counter Resistance IC Chip Inductance Capacitor Electronic Adjustable Speed Count Machine
Adjustable speed SMD parts counter Features:
1. the operation is simple, quickly really set the function.
2. can be preset the number of parts, easy to point material, hair and picking operations designed for SMD material with parts design.
3. positive and negative can count, accurate calculation of the number of zero error.
4. can be installed scanning gun and bar code printer to facilitate the management of operations.
Technical Parameters:
Model: LY-901 /901E /901S
System: ARM system, imported chip, fast response and stable performance
Speed: 10 levels of speed
Rated power: 50W
Efficiency: 25 seconds / disk
Applicable: All patch components, resistors, capacitors, ICs, etc. are suitable for disk loading
Weight about: 10kg
Counting range:-999999~999999
Motor: 42/57 motor
Two-way counting: both forward and reverse can count
Model: LY-902 /902E /902S
System: ARM system, imported chip, fast response and stable performance
Speed: 10 levels of speed
Rated power: 50W
Efficiency: 25 seconds / disk
Applicable: All patch components, resistors, capacitors, ICs, etc. are suitable for disk loading
Weight about: 10.5kg
Counting range: -999999~999999
Function: Japan high-speed side leakage induction fiber, can detect missing parts at any time, ensuring zero errors
Motor: 42/57 motor
Two-way counting: both forward and reverse can count
