Engraving area：40*50cm
Laser power : 40W/80W
Input voltage：AC 100V-240V，50 / 60Hz
Output：DC 12V 5A
Support software:LaserGRBL
Support PWM/ TTL modulate laser power
Support gray engraving, sketch route cutting, line scanning engraving, spot engraving.etc.
Laser Wavelength: 445nm (blue viole)
Laser Power: 40W/80W
Optical Power Output：5.5W/10W
Drive mode: External ACC constant current drive
Cooling Method: Forced air cooling
Operating Voltage: 12V DC
Shell Material: Aluminum,Surface Anodized
Module Material: Copper
Life Time:8,000 hours
Working Temperature:-40-75Celsius
Focal Length: 40W-23mm; 80W-50mm
Laser Module： 40W
Plywood 2mm cut : 300mm/min , S1000 , 1 Pass
Plywood 3mm cut : 250mm/min , S1000 , 1 Pass
Plywood 4mm cut : 200mm/min , S1000 , 1 Pass
Plywood 5mm cut : 100mm/min , S1000 , 1 Pass
Plywood 5mm cut : 200mm/min , S1000 , 2 Pass
MDF board 3mm cut : 100mm/min , S1000 , 1 Pass
MDF board 3mm cut : 320mm/min , S1000 , 2 Pass
Black acrylic plate 3mm : 100mm/min , S1000 , 1Pass
Black acrylic plate 5mm : 100mm/min , S1000 , 3Pass
Laser Module： 80W
Plywood 2mm cut : 500mm/min , S1000 , 1 Pass
Plywood 3mm cut : 450mm/min , S1000 , 1 Pass
Plywood 4mm cut : 400mm/min , S1000 , 1 Pass
Plywood 5mm cut : 240mm/min , S1000 , 1 Pass
MDF board 3mm cut : 180mm/min , S1000 , 1 Pass
MDF board 3mm cut : 120mm/min , S1000 , 2 Pass
Black acrylic plate 3mm : 120mm/min , S1000 , 1Pass
Black acrylic plate 5mm : 120mm/min , S1000 , 2Pass
GRBL1.1 2 axis control board,Can connect 3pin or 2pin laser module,and offline
Free software:
