I.    Package Contents:

1 x CNC Mach3 USB 6 Axis Motion Control Card

1 x USB Cable

1 x cd (mach3 version3.043.066 licence, instruction,)

1 x English Manual

II.    Features:

1. Dual-Processors, ARM+FPGA, More processing power

2. Support all versions of Mach3 (can't work with Mach4).

3. Work under 32-bit  Windows ( 98, Vista,7, 10) operating system (not including Mac OS)

4. USB jack does not need to install the driver, plug and play under all versions of Windows.

5. Full support USB hot-swappable, USB connection status monitoring at any time. Under Mach3 working state, USB cable unplugs and then plugs in, but also the normal connection.

6. Supports 6-axis linkage.

7. Maximum step-pulse frequency is 2000 KHz, can connect servo driver/stepper driver.

8. The indicator light indicates various working status, such as USB connection, Mach3 connection and so on.

9. 16 inputs.

10. Onboard isolated power supply , not need external power supply.

11. All IO port fully isolated, strong anti-interference, stable performance.

12. Support spindle speed PWM output; support spindle pulse and direction output; support spindle speed output from 0 to 10V analog voltage.

13. Support XHC series of wireless electronic mach3 MPG, such as WHB04 MPG.

14. With an aluminum shell, effectively shielding interference, stable and reliable performance.
