Independent temperature control Bga rework station IR8500 for laptop motherboards repair

solderreballing machine



It has large stock in china and moscow in russia ,today you place order ,today we will ship it at once !



Pls notice :

our package has CD ,the CD will include detail english manual(it will teach you every step ),

1 year warranty , the machine has any problems within our range of warranty ,we will free help buyer solve them at once!



Video:

https://www.youtube.com/watch?v=8wTTk9LEnf8&feature=youtu.be

Introduction

LY IR8500 Rework station for laptop motherboards, desktop computer motherboards, server boards, industrial computer boards, all kinds of game boards, communications equipment motherboards, LCD TVs and other large circuit board BGA rework.

LY IR8500 innovative designs an effective solution to general of infrared rework station vulnerable to the impact of air flow. will lead an inaccurate of temperature control can easily deal with lead-free soldering rework.

Technical Parameters

Basic Parameters
Heating	IR
Dimension	L780mmx W450mmx H260mm
Weight	18kg
Total weight	About 21 kg, vary with the  differen need of the users
Electrical Parameters
Power	220V AC
Upper Heating	IR
Size of Upper heating	80mm x 80mm
Consumption of upper heating	450W
Bottom Heating	IR
Size of Bottom heating	400mm x200mm
Consumption of Bottom heating	1600W
General power	2050W
Temperature Control
Control mode of Upper	Independent temperature control, high-precision closed-loop control, precision ± 0.5%, Alarm
Control mode of Bottom	Independent temperature control, high-precision closed-loop control, precision ± 0.5%, NO Alarm
Rework Function
SMD	Suit for welding, remove or repair packaged devices such as BGA,PBGA,CSP,multi-layer substrates, EMI metallic shield product and solder/lead free Rework welding
Size of applicable chips	≤70mm x70 mm
Size of applicable PCB	≤400mm x305mm

Packing list:

1× IR8500 BGA rework station

1x LY IR cover set

1× power cable

1× usb to rs232 port cable (with CD)

1× thermocouple

6x pcb jig with screw

1× CD of manual and software (if not get, may be lost in customs, please contact us)

1x tape
