DESCRIPTION

NEJE 3 with N30820 module is a portable and safty desktop laser engraving and cutting machine with strong engraving and cutting capabilities. This device is small in size but equipped with almost all professional functions designed by NEJE. Particularly good at engraving hardwood, glass, rubber stamps, cutting materials smaller than 170x170mm, and users who require a portable design is a very good choice. NEJE 3 also has functions such as auto air assist and auto smoke extension. MEMS gyro sensor can also protect safe use.

SPECIFICATION

FEATURES

-[170 x 170 mm] Moderate use area, and under the protection of MEMS vibration protection sensor, the engraving and cutting processes can be completed at the same time. 2266 x 2266 pixels, engraving accuracy: 338 dpi. The whole machine function test requires only 4 screws to complete the installation.

-[Advanced Laser Module] NEJE's classic multifunctional module, With about 40W machine power, 5.5-7.5W Laser Module Output Power, which weighs only 202g, can obtain high power and fast scanning performance. The minimum focus point reaches 0.08x0.08mm (N30820 module), can engrave metal, and can cut materials less than 12mm, built-in fast intelligent drive, temperature feedback can be timely, intelligently adjust the fan to reduce noise Safe and quiet to use.

-[More materials, clearer] Wood, MDF, leather, paper, cotton, etc. are all supported. 3mm plywood only needs air-assisted cutting once, and the cutting is very clean. Cover spraying can engrave stainless steel, glass, transparent acrylic and so on.

-[Portable professional control software] 32-bit control system, the fastest speed reaches 250,000mm/min, supports LaserGRBL, Lightburn, NEJE software, NEJE APP (Android, iOS, ipadOS, macOS), NEJE provides free software upgrade services.

-[Perfect after-sales service] The whole machine is guaranteed for free for 2 years (laser module: 2 years and 20,000 hours warranty), and vulnerable parts are shipped worldwide within 24 hours.

-Equipped with a high-power laser module (model: N30820), with a square focus point, it can not only complete fine wood 3D engraving, stainless steel, glass, stone and other materials engraving, but also complete clear and uniform cutting plywoord, fabric, acrylic etc.. 3-4mm plywood cutting 1 from 1 pass.

-The optimized GRBL version is perfectly compatible with lightburn, laserGRBL and NEJE series software, and has optimized working stability in lightbrun and laserGRBL modes, adjustable low light and automatic air-assisted automatic smoke extraction system expansion. Through wireless APP (android, iphone, ipad, macbook) is more portable and efficient to complete the creation of works.

EXPANSION DESCRIPTION

M7 relay expansion accessories, can be used to control AC or DC power supply smoke exhaust system, can also be used to control other circuits, used as M8, there are safety risks when operating high-voltage circuits, requiring professional operation; M8 valve expansion accessories, can be used To control the air compressor switch, neje 3 supports accessories expansion, but the relay module, air valve module and Door need to be purchased separately, not included in the product list.

About Air Assist

-It is only necessary to add air assist when cutting plywood larger than 3mm and engraving rubber stamps such as carbonized materials. Air assist below 0.4mpa does not make any sense.

About Roller

-Support almost all rollers, round wine bottles, mugs, ceramic mugs can be engraved.

Note(Please pay attention)

1. Please wear laser goggles during usage and avoid touching the laser directly with your eyes and skin!

2. Do not engrave mirror objects，Pay attention to fire，Pay attention to pets when working！

3. Smoke will be generated when burned, please pay attention to smoke exhaust indoors.

4. The warranty period of laser module is one year. If you have any quality problem(Except individual situation like using the laser module more than 30 minutes per time and casue the damage ), please feel free to ask our customer service for a help.

5. If your laser module has any problem, please DO NOT dismantle it without our permission. It will destroy the laser module.

6. If you have any quality problem about the machine, please feel free to contact us. Many operative problem can be solved according to your video and problem description. Thank you in advance.

Package Included

1 x NEJE 3 Laser Engraving Machine

1 x Laser Module  (N30820)

4 x Nuts

1 x goggle

1 x L-shaped wrench

1 x USB Cable

1 x Small wrench

1 x 12V4A Power Adapter

1 x Eu adapter

1 x Small Wooden block

1 x Test Paper
