50W Raycus Fiber Laser Marking Machine 30W 20W Metal Engraver Cards Stainless Steel Gold Silver Copp Cutting Machine with Rotary
Specifications:
Model |
|
Laser power |
20W/30W/50W Raycus (Other brand optional) |
Field Mirror(Work Area) |
200*200mm ( 50*50mm / 70*70mm / 110*110mm / 150*150mm /300*300mm Optional. Support extra purchase.） |
Cooling Mode |
Air Cooling |
Laser Wavelength |
10.64 um |
Frequency of pulse |
20-100 KHz |
Marking Depth |
≤0.3 mm |
Marking Speed |
≤4000 mm/s |
Marking Lines |
1-10 lines |
Minimum Line Width |
0.01 mm |
Minimum Character |
0.15 mm |
Repeatability Accuracy |
±0.002 mm |
Resolution Ratio |
0.1 mm |
Marking Content |
Text, pattern, date, bar code, etc |
Operation System |
Microsoft Windows XP or Windows 2000,WIN 7, WIN8, WIN 10 |
Control Software |
EZCAD ENGLISH Control Software |
Graphic Format Supported |
BMP, JPG, GIF, TGA, Ai, DXF, PLT, PNG, TIF, ai, DXF, DST, etc. |
Unit Power |
≤0.9 KW |
Operation Temperature |
5°C-40°C |
Relative Moisture |
≤ 90%, no fog |
Dimensions(L*W*H) |
95 x 78 x 55 cm |
Power supply requirements |
220 V or 110V |
Weight |
60KG |
Warranty |
24 months |
